6 Gang Universal On/Off Switch Panel Electronic Relay Circuit Control System 12V

Description

6 Gang LED Switch Panel Electronic Relay Circuit Control System Car Boat RV 12V

Specification:

Model Name: E79485

Product Name: 6 Gang Switch Panel Electronic Relay System

Material: ABS Plastic

Color: Black

Switch Lighting Color: Blue Background,Pink On

Voltage Rating: DC12V

MAX Watte: 960W

Operating Temperature: - 40° C ~ + 100° C

To Control: Fog/Driving Light

Switch Type: Push Button

Placement on vehicle: Center, Dash, Steering Column

Waterproof: Yes

Mounting Hardware Included: Yes

Over-voltlage Protection:Yes

Over-current Protection:Yes

Quantity: One set

Panel Size: 7.6cm x 7cm x 1.8cm / 3x2x0.7 inch(L x W x H)

Circuit Box Size: 12.7cm x 7.1cm x 9.4cm / 5x2.8x3.7 inch (L x W x H)

Panel Cable Length: about 153cm

Circuit Box Cable Length: about 237cm

Features:

-HIGH QUALITY DESIGN: Adopting capacitive sensing technology with blue and pink indicator light display, high sensitivity, stability and strong anti-interference ability, utilizing good quality materials in manufacturing processes result in products that deliver exceptional wear resistance performance. This universal switch panel can control 6 light bars and devices at the same time. Each circuits: 40A.

-SAFETY PROTECTION: The switch panel box with 6pcs fuses,relay and temperature protection switch,the temperature is higher than 100℃ and all the relay will be automatically disconnected,the whole circuits have over-voltage protection ,over-current protection and reverse polarity protection.

-ALL IN ONE DESIGN: Our 6 gang switch panel kit contains all accessories you need,there are mounting brackets to install switch panel,don’t need to drill hole,10pcs zip ties help you manage the wires better make sure inside tidy after installation and easy plug & play wiring harness. 24pcs reusable DIY stickers by your favor and needs.

-WIDE APPLICATION: Upgraded small size switch panel saves more space and can be mounted on dash panel, center console, dashboard, overhead sunglasses holder, etc.,widely suitable for all DC12V off road vehicle,car, truck, pick-up, atv, utv, suv, power sport, marine, boat, yacht, trailer, bus, heavy duty and so on. Maximum Power: 720-960W.

Fitment:

Suitable for Car Boat Marine RV Truck Camper Vehicle.

Package includes:

1x 6 Gang Switch Panel

1x Control Box

1x Switch Fixed Bracket

10x Zip ties

1x Button Sticker

1x Control Box Bracket

1x Double-Side Tape

1x User Manual

Note:

1.We provide clear pictures, measurements where possible. Please check as much as possible to make sure the item is the one that you need.

2.Please allow 0.5-1 inch difference due to manual measurement.(1inch=2.54cm)

3.There are no instruction included!Professional Installation Is Highly Recommended!!If you want to know how to use or install it,please contact us by Email.We will provide help as much as possible.
